FPJ140 2HP

Spacious two Half portal design

  • LPS

The FPJ140 2HP Security Portal is a large, secure door system with interlocking doors. Comprised of two half portals, it’s perfect for situations where high throughput is needed without compromising security.

The FPJ140 2HP Security Portal is a top-of-the-line, state-of-the-art door system that offers unbeatable security and a spacious design. It utilises interlocking doors to ensure maximum safety and is perfect for applications where a high level of throughput is needed without compromising security.

The FPJ140 2HP Security Portal can also be tailored to meet clients’ needs. Infill panels are available to extend the length of the interlock, creating a more spacious and comfortable portal. With its unparalleled security and customisable design, the FPJ140 2HP Security Portal is the ultimate solution for your security needs.

  • Anti-Tailgating
  • Anti-Vandal
  • Connectivity
  • High-Security
  • Low Throughput
  • Touchless

Standards & Certifications

  • LPS1175: Issue 8
  • Secured by Design Accredited
  • FB2/NS EN 1522 Top Canopy
  • FB4/NS EN 1522 Metal Structure
  • Vandal Resistant glass P2A-EN 356
Standard Feature Option
External Width x Depth 1387mm x 1907mm
Internal Width x Depth x Height 1160mm x 1725mm x 2048mm
Entrance Width 895mm
External Height 2320mm
Safety and Security
Safety Features Anti-slip Floor mat | Emergency unlocking device | Fail secure | IR safety sensors | Internal LED light | Fire alarm signal
Emergency Emergency lever, handle or crank Additional Internal Emergency Lever | Additional External Emergency Lever
Security Ratings FB2/NS EN 1522 Top Canopy
FB4/NS EN 1522 Metal Structure
Attack Resistant Attack Resistant Class RC3 EN 1627-30:2011
Attack Resistant Class RC4 EN 1627-30:2011
Vandal Resistant Glass P2A-EN 356 P4A-EN 356 | P6B-EN 356 | P7B-EN 356
Bullet Resistant Glass BR3-EN 1063 | BR4-EN 1063
Secure by Design Accredited LPS 1175: Issue 8 A1(SR1)
LPS 1175: Issue 8 B3(SR2)
LPS 1175: Issue 8 C5(SR3)
Detection Infrared presence sensors APD – Anti Piggybacking Device | 2 Zone Pressure Mat |  Reed door position tamper sensor
Connectivity Intercom (included in the traffic light)
LED Traffic lights
Web LAN Control | Internal Alcove for Access Control Systems
Control Service mode keyswitch or Multi-function control panel Additional Control Panel with Display | Emergency Exit Control Panel | 4” TFT monitor for Control Panel | Night Lock
Additional Information
Version R: Rail floor guide 12mm base – (surface mounted installation only)
K: Portal delivered in sections to be assembled at the installation site.
S: Welded portal structure with 70mm floor base – (recessed or surface mounted)
Design RAL colour (sliding door frames RAL 9005 – black) Polished steel | Brushed steel | Aluminium | RAL pearl colours
